Table 1. EU Directive Information – CE Compliance
|
Electro Magnetic Compatibility (EMC) Directive 2014/30/EU |
EN 61326-1:2013 EN IEC 61000-3-2: 2019+A1: 2021 EN 61000-3-3:2013+A2:2021 |
|
Safety Low Voltage Directive (LVD) 2014/35/EU |
EN 61010-1:2010+A1:2019 |
|
RoHS Directive 2011/65/EU |
Large Scale Fixed Installation Exclusion |
Table 2. North America
|
Electromagnetic Compatibility (EMC) |
Conforms to FCC 47 CFR Part 15 Subpart B (05/2024) Certified to CSA Std ICES-003 Issue 7 Oct 2020 |
|
Safety |
CSA C22.2 #61010-1-12:2012 Ed. 3 + U1;U2;A1 UL 61010-1:2012 Ed.3 + R:19Jul2019 |
Table 3. UK Conformity Assessment – UKCA
|
Electro Magnetic Compatibility (EMC) 2016 |
EN 61326-1:2013 |
|
Electrical Equipment Safety Regulation 2016 |
EN 61010-1:2010 |
|
Regulation Restriction of Hazardous Substances (RoHS) |
Large Scale Fixed Installation Exclusion |
Markings for EBMA-201:
|
|
|
|
|
|
|
Operating Temperature |
0˚C to 70˚C (-4˚F to 158˚F) |
|
Operating Humidity |
10% RH to 90% RH, non-condensing |
|
Enclosure Ratings |
NEMA Type 3R, 4, 4X, 12, 13 IP66 |
|
Plant-supplied power source |
120 V, 60 Hz or 240 V, 50 Hz AC |
|
Circuit breaker |
Internal 120V, 5 A |
|
Current draw under normal usage |
Approximately 0.6 A |
Table 4. EU Directive Information – CE Compliance
|
Electro Magnetic Compatibility (EMC) Directive 2014/30/EU |
EN 50663: 2017 EN 62479: 2010 |
|
Safety Low Voltage Directive (LVD) 2014/35/EU |
EN 61010-1:2010+A1:2019 |
|
RoHS Directive 2011/65/EU |
Large Scale Fixed Installation Exclusion |
|
Radio Equipment Directive (RED) 2014/53/EU |
ETSI EN 300 328 V2.2.2 (2019-07) ETSI EN 301 489-1 V2.2.3 (2019-11) ETSI EN 301 489-17 V3.2.4 (2020-09) |
Table 5. North America
|
Electromagnetic Compatibility (EMC) |
Conforms to FCC 47 CFR Part 15 Subpart B (05/2024) Certified to CSA Std ICES-003 Issue 7 Oct 2020 |
|
Safety |
Out of scope, 9VDC device |
|
Radio |
CFR47 FCC Part 15.247 Subpart C: 04/201 CFR47 FCC Part 15 Subpart B: 04/2019 RSS-247 Issue 2 02/2017 ICES-003 Issue 6: 01/2016 Updated: 04/2019 RSS-Gen Issue 5 04/2018 RSS-102 Issue 5 03/2015 KDB 558074 D01 15.247 Measurement Guidance v05r02 |
Table 6. UK Conformity Assessment – UKCA
|
Electro Magnetic Compatibility (EMC) Directive 2014/30/EU |
EN 50663: 2017 EN 62479: 2010 |
|
Safety Low Voltage Directive (LVD) 2014/35/EU |
EN 61010-1:2010+A1:2019 |
|
RoHS Directive 2011/65/EU |
Large Scale Fixed Installation Exclusion |
|
Radio Equipment Directive (RED) 2014/53/EU |
ETSI EN 300 328 V2.2.2 (2019-07) ETSI EN 301 489-1 V2.2.3 (2019-11) ETSI EN 301 489-17 V3.2.4 (2020-09) |
Markings for EBHS-001:
|
|
|
|
|
Marking for the WEEE Directive; Appears on all products sold into the EU:
|
|
|
Most Recent Recorded Values (Local) |
Configurable Brush Health Alerts (Local) |
Historical Data Trending (Output to Historian) |
|---|---|---|
|
|
See Modbus Interface for a complete list. |
The Compact Brush Condition Monitoring (cBCM) System is equipped with an integrated touchscreen user interface that provides local configuration, visualization, and system status monitoring. An optional secondary display may be installed to support additional viewing locations. The cBCM System communicates wirelessly with the Brush Health Sensors using a 2.4 GHz RF Bluetooth® Low Energy (BLE) connection, enabling reliable data transmission in industrial environments. For integration with plant DCS or historian systems, the cBCM System supports multiple data output interfaces, including Modbus TCP/IP over Ethernet, Modbus RS‑232, and Modbus RS‑485.
If desired, the Modbus data from the cBCM System can be inputted into Cutsforth’s InsightCMTM software. For more information on InsightCMTM, including specific server requirements, visit the InsightCMTM README on the Cutsforth Support webpage at https://support.cutsforth.com.
